Wire,Cable Length Measuring Machine Model CCDD-60L

Wire,Cable Length Measuring Machine, Length measurement, Wire, Cable meter counter gauge.

Technical parameters:

Operating voltage: ~ 220V plus/minus 15% 50 - 60Hz

Power consumption: <10W

Operating temperature: -10 ~ 40 Degrees Celsius

The model CCDD-60L is used for measuring the length of cable ( external diameter between 1mm -60mm )

Photo 1 : Model CCDD-60L Measuring head (with Stand)

Accuracy: 0.1%

External dimensions: 350mm * 150mm *1500mm

Support adjust height : 200mm-1450mm

Photo 2: Electronic Counter

Electronic Counter

Maximum count: 10Km

Measurable length: 0-99999.99m

Cumulative length: 0-9999999m

Calibrate measuring precision.

Protection data when Power Down.

Pre-setting the length.

Pre-setting alarm length.

External dimensions: 160mm * 80mm * 170mm

Installation hole size: 152mm * 76mm

Package Size: 38 cm * 34 cm * 20 cm ( Measuring unit volume )

7 cm * 8 cm *145 cm (Stand Volume )

Packaging Weight: 22KG
